Yakovlev Yak-9

National origin:- Soviet Union
Role:- Fighter
Manufacturer:- Plant No.153 (Novosibirsk), Plant No.166 (Omsk), Plant No.82 (Moscow)
Design group:- A.S. Yakovlev Design Bureau
First flight:- 6th July 1942 (Yak-7DI)
Introduction:- October 1942
Status:- Retired 1950 (Soviet Air Forces), 1951 (Korean People's Army Air and Anti-Air Force), 1955 (Bulgarian Air Force)
Produced:- October 1942 - December 1948
Number built:- 16,769[1]
Primary users:- Soviet Air Forces; French Air Force (Normandie-Niemen); Polish Air Force; Yugoslav Air Force
Developed from:- Yakovlev Yak-7

Origins

Origins

The Yakovlev Yak-9 (Russian: Яковлев Як-9) was a single-engine single-seat multipurpose fighter aircraft used by the Soviet Union in World War II and after. It was a development of the robust and successful Yak-7B fighter which was based in turn on a tandem-seat advanced trainer Yak-7UTI. The Yak-9 started arriving in Soviet fighter aviation regiments in late 1942 and played a major role in retaking air superiority from the Luftwaffe's new Focke-Wulf Fw 190 and Messerschmitt Bf 109G fighters during the grand Battle of Kursk in summer 1943.

The Yak-9 had a cut down rear fuselage with an all-around vision canopy. Its lighter metal structure allowed for an increased fuel load and armament over previous models build from wood.[2] Yak-9 was manoeuvrable at high-speed at low and medium altitudes and easy to control, which made it one of most produced Soviet fighters of World War II. It was produced in different variants including the Yak-9T with the 37 mm (1.5 in) cannon and the 'large-calibre' Yak-9K with a 45 mm (1.77 in) cannon firing through propeller hub to be used against tanks and aircraft, the fighter-bomber Yak-9B with an internal bomb bay behind cockpit for up to 400 kg (880 lb) bombs, the long-range Yak-9D and the Yak-9DD with additional wing fuel tanks to escort bombers over Eastern Europe, and the Yak-9U with a more powerful engine and improved aerodynamics. The Yak-9 remained in production from 1942 to 1948, with 16,769 built (14,579 during the war).[3]

After World War II, the Yak-9 would also be used by the North Korean Air Force during the Korean War.[4]

Design and development

Design and development

The Yak-9 represented further development of the successful Yakovlev Yak-7 fighter, a production version of the lightened Yak-7DI, taking full advantage of the combat experience with its predecessor. Greater availability of duralumin allowed for lighter construction which in turn permitted a number of modifications to the basic design. Yak-9 variants used two different wings, five different engines, six different fuel tank configurations and seven different armament setups.

Yak-9U

During December 1943, the new airframe (Yak-9U) was able to use the M-107A engine, which was more powerful than the previous VK-105PF. The engine installation was new and included individual faired exhaust pipes. The oil cooler intake was moved from beneath the nose to the port wing root as well as an enlarged radiator bath being moved further aft under the fuselage. A supercharger intake was centered on the top decking of the engine cowling. The rear antenna cable was moved inside a lengthened rear canopy which provided the pilot with a better view to the rear, while the rear fuselage was cut down and the horizontal tail surfaces were slightly reduced in size. The wings and fuselage structure were made of metal which was then skinned with Bakelite. The Yak-9U was typically armed with a 20 mm (0.79 in) ShVAK cannon firing through the hollow propeller shaft, and two 12.7 mm (0.50 in) Berenzin UB machine guns.[5]

State trials were carried out from January to April 1944 and revealed that the Yak-9U had a better top speed compared to fighters in service on the Eastern front at 6,000 m (20,000 ft). Unlike the I-185 the Yak-9U was more stable and easier to fly. Unfortuneatly the M-107A engine inherited the problems of the VK-105PF and was prone to overheating, oil leaks, loss of engine pressure during climbs, spark plugs constantly burning out, and intense vibrations which would fatigue assembly bolts leading to a short engine life. These defects forced the first production batches starting during April 1944 to be powered by the more reliable M-105 PF-3 engine. Further changes were made increasing to 400 l (88 imp gal; 110 US gal) and in order to re-balance the aircraft, the wings were moved 9.9 cm (3.9 in) forward and the aircraft's Vlsh-107LO propeller being replaced with the older VISH-105S. A total production of 1,134 aircraft were constructed by December 1944.[5]

Operational history

Operational history

Second World War

The first Yak-9 entered service in October 1942 and saw combat the same year. The Yak-9 operated with a wide variety of armament for use in anti-tank, light bomber and long-range escort roles. At low altitude, in which it operated predominantly, the Yak-9 was more maneuverable than the Bf 109. A series of improvements in performance and armament did not degrade the handling characteristics. Soviet pilots regarded the Yak-9's performance as being comparable to the Bf 109G and Fw 190A-3/A-4.[6] After the Battle of Smolensk, in the second half of 1943, the famed Free French Normandie-Niémen unit became a Groupe and was equipped with the Yak-9.[7]

The first unit to use the Yak-9U, between 25 October and 25 December 1944, was 163IAP. Pilots were ordered not to use the engine at combat speed since this reduced its life to two or three flights only. Nevertheless, in the course of 398 sorties, the unit claimed 27 Focke-Wulf Fw 190As and one Bf 109G-2, for the loss of two Yaks in dogfights, one to flak and four in accidents. The Yak-9U contributed greatly toward the Soviets gaining air superiority, and the Germans learned to avoid the Yaks 'without antenna mast'.[8]

A large formation of the Yak-9DD version was transferred to Bari (the capital of Apulia, in Italy) to help Yugoslav partisans in the Balkans.[9]

One of the top-scoring Yak-9 pilots was First Lieutenant A.I. Vybornov. Flying a type-T (equipped with a 37mm NS-37 cannon in the nose) he achieved 19 air victories, plus nine shared and was awarded the Gold Star Medal of the Hero of the Soviet Union in June 1945.[10] At the end of the war, on 22 March 1945, Lieutenant L.I. Sivko from 812th IAP achieved the air victory against a Messerschmitt Me 262 jet fighter, but he was killed soon afterward by another Me 262, probably piloted by Franz Schall, a top-scoring Me 262 pilot.[11]

Fighter units with this aircraft suffered lower losses than average. Of 2,550 Yak-9s manufactured up the end of 1943, only 383 were lost in combat.[12]

Post-war era

During 1949, the Soviet Union provided surplus Yak-9P (VK-107) aircraft to some satellite states in the Soviet bloc to help them rebuild their air forces following the West Berlin blockade. A section of the aircraft's operating manual was accidentally omitted from the translation from Russian into some languages: before starting the Yak-9, it was necessary to hand-crank a small cockpit-mounted oil pump 25 times to provide initial lubrication to the Klimov V12 engine, unlike World War II German and Western fighters equipped with forced closed-cycle lubrication systems. Skipping this unusual but vital step resulted in frequent engine seizures during the takeoff roll and initial climb, causing several fatalities during 1950.

Variants

Variants

Yakovlev OKB created 22 modifications of the Yak-9, of which 15 saw mass production. The most notable of these include:

Yak-9

First production version, Klimov M-105PF engine with 880 kW (1,180 hp), 1 × 20 mm (0.79 in) ShVAK cannon with 120 rounds and 1 × 12.7 mm (0.50 in) UBS machine gun with 200 rounds.

Yak-9 (M-106)

Prototype with Klimov M-106-1SK engine with 1,007 kW (1,350 hp), did not advance to production because of problems with the engine.

Yak-9T

Yak-9 armed with a 37 mm (1.5 in) Nudelman-Suranov NS-37 cannon with 30 rounds instead of the 20 mm (0.79 in) ShVAK, cockpit moved 0.4 m (1 ft 4 in) back to compensate for the heavier nose. Initially poor quality control led to multiple oil and coolant leaks from cannon recoil.(It was a problem only during the prototype tests:[13] )Recoil and limited supply of ammunition required accurate aiming and two-three round bursts. Yak-9T was widely used against enemy shipping on the Black Sea and against tanks (the cannon could penetrate up to 30 mm (1.2 in) armor from 500 m (1,600 ft), but was also successful against aircraft with a single cannon hit usually sufficient to tear apart the target. Virage (constant altitude and velocity turn) time: 18-19 seconds. 2748 were produced.[14]

Yak-9K

Yak-9T modified with a 45 mm (1.8 in) NS-45 cannon with 29 rounds and a distinctive muzzle brake to deal with the massive recoil. Firing the cannon at speeds below 350 km/h (220 mph) caused dramatic loss of control and tossed the pilot back and forth in the cockpit; however, accurate shooting was possible at higher speeds and in 2-3 round bursts. The recoil also caused numerous oil and coolant leaks. The heavy cannon installation degraded performance, even more so at high altitudes, sufficiently to relegating the Yak-9K to be used as a heavy fighter and resulting in the need for a fighter escort of Yak-3s. The Yak-9K saw only limited use due to unreliability of the NS-45, airframe performance issues caused by both the NS-45 and larger fuel tanks used on the Yak-9K, as well as a reduction of bombers used by the Germans.

Yak-9D

Long-range version of Yak-9, fuel capacity increased from 440 to 650 l (97 to 143 imp gal; 120 to 170 US gal) to giving a maximum range of 1,400 km (870 mi). Combat usefulness at full range was limited by lack of radio navigation equipment, and a number of aircraft were used as short-range fighters with fuel carried only in inner wing tanks. Circle time: 19-20 sec. Weight of fire: 2 kg/s (260 lb/min).

Yak-9TD

Yak-9D with NS-37 cannon and provision for 4 × 50 kg (110 lb) FAB-50 bombs under the wings.

Yak-9B

Fighter-bomber version of Yak-9D (factory designation Yak-9L) with four vertical tube bomb bays aft of the cockpit with capacity for up to 4 × 100 kg (220 lb) FAB-100 bombs or 4 PTAB cassettes with 32 × 1.5 kg (3.3 lb) bomblets each, although normally only 200 kg (440 lb) of weapons were carried in the front bomb bays. Poor handling with a full bomb and fuel load and lack of special aiming equipment limited combat usefulness.

Yak-9DD

Yak-9D and Yak-9T modified to further increase the range, fuel capacity increased to 845 l (186 imp gal; 223 US gal) giving a maximum range of 2,285 kilometres (1,420 mi), radio navigation equipment for night and poor weather flying. Yak-9DD were used primarily to escort Petlyakov Pe-2 and Tupolev Tu-2 bombers although they proved less than ideal for this role due to insufficient speed advantage over the bombers. In 1944, several Yak-9DD were used to escort B-17 Flying Fortress and B-24 Liberator bombers attacking targets in Romania using the Ukraine-Romania-Italy routes.

Yak-9M

Yak-9D with the cockpit moved 0.4 m (1 ft 4 in) to the rear like on Yak-9T, numerous fixes and improvements based on experience with previous versions.

Yak-9M PVO

Yak-9M with slightly reduced fuel capacity, Klimov VK-105PF2 engine with 925 kW (1,240 hp), and radio and navigational equipment for night and adverse weather flying for PVO Strany.

Yak-9 MPVO

Single-seat night fighter aircraft, equipped with a searchlight and an RPK-10 radio compass.

Yak-9S

Yak-9M with Klimov VK-105PF engine, new propeller, and armament consisting of 1 × 23 mm (0.91 in) Nudelman-Suranov NS-23 cannon with 60 rounds, and 2 × 20 mm (0.79 in) Berezin B-20 cannons with 120 rounds. Did not enter production due to poor performance compared to Yak-3 and Yak-9U.

Yak-9R

Single-seat tactical reconnaissance aircraft.

Yak-9P

This aircraft was the last and the most advanced version of the Yak-9 fighter, which became the pinnacle of development among A. S. Yakovlev's piston-engined fighters. The Yak-9P (Product P) that appeared in 1946 was a modification of the Yak-9U fighter of composite construction. Unlike its predecessor, it had all-metal wings with elliptical tips. By this time, the manufacture of high-strength aluminum alloys was established in the Soviet Union, simplifying aircraft operation and increasing aircraft service life.

Yak-9P (VK-107)

Yak-9U with an all-metal wing, Yak-9P in this case was a factory designation different from Yak-9P with two ShVAKs (see above).

Yak-9PD

High-altitude interceptor (unrelated to the two other Yak-9P above) with Klimov M-105PD engine designed specifically to intercept Luftwaffe Junkers Ju 86P high-altitude reconnaissance aircraft overflying Moscow in 1942-1943. Initially poor performance due to unreliable engine dramatically improved with adoption of Klimov M-106PV with water injection, with the aircraft reaching 13,500 m (44,300 ft) during testing. Armament reduced to the ShVAK cannon only to save weight.

Yak-9U (VK-105)

Yak-9T with Klimov VK-105PF2 engine and numerous aerodynamic and structural improvements introduced on Yak-3. Main visual difference from Yak-9T was in the oil coolers in the wing roots like on Yak-3 and in plywood covering of the fuselage instead of fabric. Visually differed from Yak-3 only by main landing gear covers. Armament increased to 1 × 23 mm (0.91 in) VYa with 60 rounds and 2 × 12.7 mm (0.50 in) UBSs with 170 rpg. The VYa cannon could be replaced by a ShVAK, B-20, or NS-37, the latter requiring removal of the starboard UBS machine gun. Did not enter production because the VYa cannon was considered unsatisfactory and because the one cannon, one machine gun armament seen on previous models offered a significant increase in range.

Yak-9U (VK-107)

The definitive Yak-9 variant, Yak-9U (VK-105) equipped with the new 1,230 kW (1,650 hp) Klimov VK-107A engine, and the 20 mm (0.79 in) ShVAK with 120 rounds replacing the VYa. Weight of fire: 2.72 kg/s (6.0 lb/s). Early test flights in 1943 indicated that the only comparable Soviet fighter was Polikarpov I-185 prototype which was more difficult to fly and less agile due to higher weight. The prototype's top speed of 700 km/h (430 mph) at 5,600 m (18,400 ft) was faster than any other production fighter aircraft in the world at the time, other than the P-51B that could reach up to 710 km/h (441 mph) on military power.[15] Early problems with overheating were fixed by enlarging the radiators and production aircraft had further improved aerodynamics. Turning ability to complete a circle: 23 sec, best Soviet fighter at altitude.

Yak-9UV

Two-seat trainer version of Yak-9U (VK-107), armament reduced to a single Berezin B-20 cannon with 100 rounds. Did not enter production due to introduction of jet aircraft.

Yak-9UT

Yak-9U (VK-107) armed with 1 × 37 mm (1.5 in) Nudelman N-37 cannon with 30 rounds and 2 x 20 mm (0.79 in) Berezin B-20 cannons with 120 rpg, giving a total one-second burst mass of 6 kg (13 lb). Similarly to the Yak-9TK, it could be converted to replace the N-37 with a 20 mm (0.79 in) B-20, 23 mm (0.91 in) NS-23, or 45 mm (1.8 in) N-45. Production aircraft carried NS-23 instead of the N-37 cannon as the default armament.

Yak-9-57

The Yak-9-57 was a one-off conversion of a Yak-9UT armed with a 57 mm cannon.[16] The large caliber cannon did not protrude out from the spinner cone like the Yak-9-37/45 models.

Yak-9V

Two-seat trainer version of Yak-9M and Yak-9T, Klimov VK-105PF2 engine, armament reduced to 1 × 20 mm (0.79 in) ShVAK with 90 rounds.

Modern replicas

In the early 1990s, Yakovlev started limited production for the warbird market of Yak-9 and Yak-3 replica aircraft using original World War II equipment and Allison V-1710 engines. These modern-built replicas using the Allison engines, have counterclockwise-rotation props, unlike the originals which strictly used clockwise-rotation Soviet V12 powerplants.

Operators

Operators

Albania

Albanian Air Force received 72 aircraft in 1947, including 12 Yak-9V trainers.

Bulgaria

Bulgarian Air Force

People's Republic of China

People's Liberation Army Air Force

Free French Air Force

Normandie-Niemen Fighter Squadron

Hungary

Hungarian Air Force received aircraft in 1949. The type's Hungarian name was 'Vércse' (Kestrel).

Mongolia

Mongolian People's Army Aviation received 34 aircraft in late June 1945.

North Korean

North Korean Air Force

Poland

Air Force of the Polish Army
Polish Air Force operated several aircraft from 1947 to 1953.
Polish Navy

Soviet Union

Soviet Air Forces
Soviet Air Defence Forces

Yugoslavia

SFR Yugoslav Air Force - 16 Yak-9T, 40 Yak-9P, 47 Yak-9D/M and 68 Yak-9V aircraft in 1944-1950/1960[17]
111th Fighter Aviation Regiment (1947-1948)
112th Fighter Aviation Regiment (1947-1948)
94th Fighter Aviation Regiment (1948-1952)
116th Fighter Aviation Regiment (1948-1950)
117th Fighter Aviation Regiment (1948-1950)
141st Training Aviation Regiment (1952-1953)
2nd Training Aviation Regiment (1946-1948)
101st Fighter-Training Aviation Regiment (1948-1950)
103rd Reconnaissance Aviation Regiment (1950-1951)
104th Training Aviation Regiment (1948-1950)
Training Squadron of 32nd Aviation Division (1953-1959)
Training Squadron of 39th Aviation Division (1953-1959)
Training Squadron of 44th Aviation Division (1953-1954)

Surviving aircraft

Surviving aircraft

Bulgaria

Yak-9P on display at the Aviation Museum in Krumovo, Plovdiv.[18] It is tactical number 27.

Poland

Yak-9P on static display at the Museum of the Polish Navy in Gdynia, Pomerania.[19] It is tactical number 2 and was used by the Navy Aviation Escadrille until 1956. On 12 December 1956, it was transferred to the museum on behalf of the Navy Command.
Yak-9P on static display at the Museum of the Polish Army in Warsaw, Mazovia.[20][21] It is tactical number 23 and was used by the 1st Fighter Aviation Regiment from 1947 until 1950. It was transferred to the museum on 10 August 1950 on behalf of the Air Force Command.

Russia

Yak-9U on static display at the Central Air Force Museum in Monino, Moscow Oblast.[22]
Yak-9 on static display at the Vadim Zadorozhny Museum of Technology in Krasnogorsky District, Moscow Oblast.[23]
Yak-9 on static display at the Museum of the Air Forces of the Northern Fleet in Safonovo, Murmansk Oblast.[24]

Serbia

Yak-9P in storage at the Aeronautical Museum Belgrade in Surčin, Belgrade.[24]

Ukraine

Yak-9 on static display at the National Museum of the History of Ukraine in the Second World War in Kyiv.

United States

Yak-9U on static display at the Museum of Flight in Seattle, Washington.[25]

Specifications (Yak-9U)

Data from [26] [27]

General characteristics

    Crew: 1
    Length: 8.55 m (28 ft 1 in)
    Wingspan: 9.74 m (31 ft 11 in)
    Height: 3.00 m (9 ft 10 in)
    Wing area: 17.15 m2 (184.6 sq ft)
    Airfoil: root: Clark YH (14%); tip: Clark YH (10%)[28]
    Empty weight: 2,512 kg (5,538 lb)
    Gross weight: 3,204 kg (7,064 lb)
    Fuel capacity: 355 kg (782.6 lb)
    Powerplant: 1 × Klimov VK-107A V-12 liquid-cooled piston engine, 1,118.55 kW (1,500.00 hp)
    Propellers: 3-bladed variable-pitch propeller, 3.00 m (9 ft 10 in) diameter

Performance

    Maximum speed: 676 km/h (420 mph, 365 kn) at 5,900 m (19,400 ft)
    Range: 675 km (419 mi, 364 nmi)
    Service ceiling: 10,850 m (35,600 ft)
    Rate of climb: 18.9 m/s (3,720 ft/min)
    Wing loading: 186.82 kg/m2 (38.26 lb/sq ft)
    Power/mass: 0.35 kW/kg (0.21 hp/lb)

Armament

    Guns:
    1 × 20 mm (0.79 in) ShVAK cannon, 120 rounds
    2 × 12.7 mm (0.50 in) UBS machine guns, 340 rounds
